OVERVIEW
—
The Cat® 313 GC excavator matches its performance to your job. A new, larger cab with an ergonomic layout keeps you comfortable all shift long. Combined with fuel-saving features, longer maintenance intervals, and simplified maintenance points, the 313 GC provides the reliability you expect at the low-cost-per-hour you need.
UP TO 10% Two power modes and a new control valve and electro-hydraulic pump minimize fuel use and increase engine efficiency. | UP TO 25% LOWER With extended and more synchronized maintenance intervals, you get more done at a lower cost compared to the previous model. | ENHANCED New, larger cab provides the space and visibility you need to keep you working comfortably and safely all day long. |
PRODUCT SPECIFICATIONS FOR 313 GC
—
| Engine Model | Cat C3.6 |
| Engine Power - ISO 14396 | 55.4 kW |
| Bore | 98 mm |
| Stroke | 120 mm |
| Displacement | 3.6 l |
| Main System - Maximum Flow | 247 L/min (65 gal/min) |
| Maximum Pressure - Equipment | 35000 kPa |
| Maximum Pressure - Travel | 35000 kPa |
| Maximum Pressure - Swing | 26000 kPa |
| Swing Speed | 11.5 r/min |
| Maximum Swing Torque | 35 kN·m |
| Operating Weight | 13800 kg |
| Fuel Tank Capacity | 258 l |
| Cooling System | 15 l |
| Engine Oil | 8 l |
| Final Drive - Each | 3 l |
| Hydraulic System - Including Tank | 145 l |
| Hydraulic Tank | 70 l |
| Boom | Reach 4.65 m (15'3") |
| Stick | Reach R3 m (9'8") |
| Bucket | GD 0.53 m³ (0.69 yd³) |
| Shipping Height - Top of Cab | 2810 mm |
| Handrail Height | 2810 mm |
| Shipping Length | 7780 mm |
| Shipping Length - with Blade | 8050 mm |
| Tail Swing Radius | 2190 mm |
| Counterweight Clearance | 916 mm |
| Ground Clearance | 446 mm |
| Track Length | 3750 mm |
| Length to Center of Rollers | 3040 mm |
| Track Gauge | 1990 mm |
| Transport Width | 2490 mm |
| Maximum Digging Depth | 6040 mm |
| Boom | Reach 4.65 m (15'3") |
| Stick | Reach R3 m (9'8") |
| Bucket | GD 0.53 m³ (0.69 yd³) |
| Maximum Reach at Ground Level | 8660 mm |
| Maximum Cutting Height | 8830 mm |
| Maximum Loading Height | 6420 mm |
| Minimum Loading Height | 1600 mm |
| Maximum Depth Cut for 2440 mm (8 ft) Level Bottom | 5860 mm |
| Maximum Vertical Wall Digging Depth | 5190 mm |
| Minimum Working Equipment Radius | 2570 mm |
| Bucket Digging Force - ISO | 98.67 kN |
| Stick Digging Force - ISO | 59.29 kN |
| Air Conditioning | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.85 hg of refrigerant which has a CO2 equivalent of 1.216 metric tonnes. |
